Purified Multi-walled carbon nanotubes (TNM1):
Product Code : TNMP1, TNMPH1, TNMPC1
Technical Data (pdf)
|
TNMP1 (Download)
|
TNMPH1 (Download)
|
TNMPC1 (Download)
|
Product Description:
TimestubTM --Purified Multi-walled carbon nanotubes---There are three kinds of products in this catalog: TNM1, TNMH1 and TNMC1. TNM1 is produced by natural gas catalytic decomposition over Co-based catalyst.TNMH1 and TNMC1 are TNM1 hydroxyl and carboxyl derivates, respectively. They are produced by KMnO4 oxidation in H2SO4 solution at different temperature and KMnO4 concentration.
| Property | Unit | MWCNTs | Method of Measurement | ||
| TNMP1 | TNMPH1 | TNMPC1 | |||
| OD | nm | 5-15 | 5-15 | 5-15 | HRTEM,Raman |
| Purity | wt% | >99 | >99 | >99 | TGA & TEM |
| Length | microns | 10-30 | 10-30 | 10-30 | TEM |
| SSA | m2/g | 220-300 | ?220-300? | ?220-300? | BET |
| ASH | wt% | <1 | <1 | <1 | TGA |
| Ig/Id | -- | -- | -- | -- | Raman |
| -OH Content | wt% | XPS & Titration | |||
| -COOH Content | wt% | XPS & Titration | |||
| OD=Outer Diameter ID=Inner Diameter SSA=Specific Surface Area | |||||
