Purified Multi-walled carbon nanotubes (TNM7)：
Product Code: TNM7, TNMH7, TNMC7
Technical Data (pdf)
Product Description:
TimestubTM --Purified Multi-walled carbon nanotubes---There are three kinds of products in this catalog: TNM7, TNMH7 and TNMC7. TNM7 is produced by natural gas catalytic decomposition over Ni-based catalyst. TNMH7 and TNMC7 are TNM7 hydroxyl and carboxyl derivates, respectively.
| Property |
Unit |
MWCNTs |
Method of Measurement |
| TNM7 |
TNMH7 |
TNMC7 |
| OD |
nm |
30-50 |
30-50 |
30-50 |
HRTEM,Raman |
| Purity |
wt% |
>98 |
>98 |
>98 |
TGA & TEM |
| Length |
microns |
<10 |
<10 |
<10 |
TEM |
| SSA |
m2/g |
>80 |
>100 |
>90 |
BET |
| ASH |
wt% |
<2 |
<2 |
<2 |
TGA |
| Ig/Id |
-- |
-- |
-- |
-- |
Raman |
| -OH Content |
wt% |
|
1.06 |
|
XPS & Titration |
| -COOH Content |
wt% |
|
|
0.73 |
XPS & Titration |
| OD=Outer Diameter ID=Inner Diameter SSA=Specific Surface Area |
