Product Code : TNSS, TNSSH, TNSSC
Technical Data (pdf)
Product Description:
Timestub
TM --Short purified Single-walled carbon nanotubes---There are three kinds of products in this catalog: TNSS, TNSSH and TNSSC. TNSS is produced by mechanical cutting purified single-walled carbon nanotubes, then experienced dis-agglomeration operation. TNSSH and TNSSC are TNSS hydroxyl and carboxyl derivates, respectively.
| Property |
Unit |
Short-Length SWCNTs |
Method of Measurement |
|
TNSS
|
TNSSH
|
TNSSC
|
| OD |
nm |
1-2 |
1-2 |
1-2 |
HRTEM,Raman |
| Purity |
wt% |
>90 |
>90 |
>90 |
TGA & TEM |
| Length |
microns |
1-3
|
1-3 |
1-3 |
TEM |
| SSA |
m2/g |
>340 |
>380 |
>380 |
BET |
| ASH |
wt% |
<5 |
<5 |
<5 |
HRTEM,TGA |
| Ig/Id |
-- |
>9 |
>9 |
>9 |
Raman |
| -OH Functionalized |
wt% |
|
3.96 |
|
XPS & Titration |
| -COOH Functionalized |
wt% |
|
|
2.73 |
XPS & Titration |
| OD=Outer Diameter ID=Inner Diameter SSA=Specific Surface Area |
